Services & Innovation¶
ISOTEL is high-tech company developing sensors, data-acquisition, power and control electronics, for the industry, sport and commercial sectors. For over 10 years we offer Research and Product Development activities for:
Concept Design and Feasibility Studies
Innovation protected by Patents
Product Development and Compliance Testing
Automated Production and Reliability Tests
Partnered EMS, or transfer to your preferred EMS
For more information Contact Us
Lowest Component Count, Single Chip PFC/LLC Controller¶
Isotel in partnership developed a single-chip two-stage tightly coupled PFC and LLC converters: PFC controller that uses coil feedback sensing to reduce component count, eliminates the need for high-voltage resistors, operating in DCM, CrCM and CCM modes, and a high efficiency LLC featuring primary-side voltage regulation.
It meets latest efficiency requirements, as well as <60 mW at no-load.
Innovative Current Sensing Technology¶
Technology provides state-of-the-art wide-bandwidth DC sensors for Motor Control, Power Supplies, Battery Management Systems, Safety Leakage Measurement, and Test and Measurements.
Danfoss Valve Actuators for Heating and Cooling¶
Isotel developed electronics and firmware for the Danfoss Valve Actuators, 65x Series.
Project challenges includes a reliable system with real-time force, position, speed control loops, fine regulation and compensations of the safety spring-up/down function, and powering and driving the actuator from energy limited 3 point pulse control, log/lin compensation with protection functions. System powers from either constant 24/240 Vac, complies to national standards.
ANKA Control Electronics for Synchrotron¶
Project included development of distributed precision digital/analogue control electronics for magnet power supplies, detectors and interfaces to diagnostic equipment.
Iskratel ATCA Altera Stratix FPGA Design¶
Telecommunications FPGA VHDL Design and Implementation of Altera Stratix FPGA Controller for use in VoIP processing.
Services were also provided to following customers and others developing:
|
|
|
We do early stage development and create new concepts and methods¶
It is our mission to be engaged in projects that are aligned with future trends, either as break through innovations or as industrialization of concepts their cost reduction ready for mass production.
We use and have upgraded simulation environments for comprehensive mixed domain system level simulation, which includes the following worlds together:
mixed signal analog and digital,
VHDL and Verilog programmable logic,
embedded code blocks of algorithms, filters, and control loops, written in C, C++, python and others,
and in addition we are keen to include mechanical models and do 3D animation to represent simulation results.
To demonstrate feasibility simple proof of concepts with short time to markets are shown using development kits or existing hardwares.
Our experience includes current sensor development, switching power supplies, sensor network protocol development, sensor streaming applications, single-chip designs for embedded real-time system.
We deliver complete hardware products with firmware and software support¶
Most of our projects relate to real-time systems and include connectivity with host, and back-end services, from ARM embedded designs, FPGA/CPLD designs, battery operated sensors, sensor technologies and measurement systems.
Our expertise includes:
mechanical/plastic CAD,
electronics CAD,
technology transfer to EMS (assembly of prototypes),
firmware development,
back-end software development,
desktop and mobile app and web front-end.
Reliable and long lasting Products¶
We are equipped to design and test hardware products using automated test environments in the following ranges:
temperature from -40 to 150 oC
embedded CPU performance up to 2 GHz
analyze peripheral digital bus up to 400 MHz
signal acquisition up to 1 GHz @ 10 GSa/s and fully featured testing with Rohde & Schwarz
RF performance up to 3 GHz
DC currents up to 150 A, generation up to 40 A, and AC up to 2 MHz @ 6 A
AC power mains anomalies testing up to 3 kW @ 500 Vac
DC, AC, digital clock performance and stability testing
In addition we use methodologies as FMEA to reduce risks of hazard hardware failures, and use external services for compliance testing, according to products’ standards.
Advanced Project Management & Reporting¶
We have developed our internal closed loop Project Management system to accurately plan, coordinate activities, record progress and report on weekly and monthly basis.
We have developed own Drive Response methodology to recruit the most skilled personnel.
Instant Communication¶
We are an international team experienced in providing instant remote support to our partners as well as on-site support for hardware evaluation.
We use and have developed modern tools to support hardware development over internet and VPN’s to easily support customers worldwide, during development, testing and ramp-up in production.
Secure & Private IT Infrastructure¶
We own a secure IT/VPN TLS-based infrastructure to be able to collaborate on high confidentiality projects, including patents, and mission critical projects by following RFC 2196.
